Z Purlin Machine

By HANGZHOU ZHONGYUAN MACHINERY FACTORY

500000

HANGZHOU ZHONGYUAN MACHINERY FACTORY

China

We are manufacturer for metal roll forming machine since 2003. Good quality and reasonable rate for our customers. 1.Zhongyuan is a from raw material to the final high-precision forming machine.All are done in our factory. Your machine quality and delivery time can be controlled here if you choose us. 2.With technical support by our 20 years experienced engineers and technicians, you can get our suggestion and solution within 24 hours. 3.You can get guarantee lifetime services for our machines. 4.Simple to install and easy to maintain. >> Our machines are well installed and tested before delivery. You only need to connect some tubes and wires in your factory. Video and manual will show you how to do. >> Our experience technicians can go to your factory and train your workers. >> We have exported 85 sets machines to India since 2008. You can trust our experience and solution for your deal between us.

Other Details

ESTD. From

2003

Number Of Employees

Annual Turnover

Rs 180000000 Lakhs

Z purlin machine

1. Components for the Machine:
The purline forming line includes in manual decoiler, sheet leveling equipment, roll forming system, punching equipment, post-cutting equipment, hydraulic station, electric controlling system and supporter for purline.

2. Technical Parameters
Machine Dimension: About 18000mm2400mm1400mm
Suitable material: Galvanization steel sheet
Product Spec: (100,120,140,160,180,200,220,240)mm2.0-3.0mmL
(Widththicknesslength)
Forming Speed: 8000 10000 mm/min.
Power Requirement: Main motor power: 15 Kw-4 Depend on final design
Hydraulic station power: 5.5 Kw Depend on final design
Decoiler: Max. Capacity: 3000kgs
Main roller qty: about 16 stands
Control system: Mitsubishi PLC and converter
Diameter of shaft: 82mm
Type of cutting: length-set cutting and post forming style
Hydraulic pressure: 18-20 Mpa
Electric condition: 415V/3Phase/ 50HZ
Total weight: About 9500kg

Packing:
1. One 40feet container for loading one set machine with decoiler.
2. Main machine body and decoiler is load naked (tighten to container with steel wire rope).
3. Spare parts and operating tools are loading in tooling box.

Delivery : about 70 days after received advaced payment

Trade terms: FOB, C&F, CIF available.

About us
1. Customize roll forming machines since 2003.
2. Capacity: 12-15 sets/month
3. Delivery: in only 5-8 weeks for urgent order
4. Company occupies 6650, in which 5650 for workshops
5. Have our own tool center
